Iron-On Twill Reflective Tape in 5cm Silver Finish
5cm Iron-On Silver Reflective Heat Transfer Tape
Model: 6804-1009
Backing Fabric Material: | 100% Polyester |
Width: | 5.0cm |
CPL: | 260≤CPL≤330 |
Type: | Heat Transfer Reflective Film |
Color: | Grey, Silver, Yellow, Orange (custom ones available) |
Packaging: | 50-200m/roll |
MOQ: |
|
MH Reflective Tape Factory
50,000m²
Plant Area
$10 million
Annual Sales Amount
500,000m²
Month Production
About Ningbo MH
MH specializes in garment accessories and fabrics, offering high-quality solutions for the textile and home décor industries. With advanced automated warehousing, MH ensures efficient supply chain management and provides comprehensive after-sales support, exclusively serving businesses, not individuals.
1999
Since
$871Million
Annual Sales
40+
Branch Offices
600+
Staffs
Product Details
Heat Transfer Twill Reflective Tape
Color: Orange/Silver
Process: Iron on/Heat transfer
MH twill iron-on reflective tape is a 5cm wide heat-transfer trim woven from 100% polyester twill and finished with a reflective film rated CPL 260–330.
The tape bonds to fabric under a household iron or heat press, so it applies without stitching and sits flush against the garment surface.
Key Selling Points
Heat-transfer application: MH twill reflective tape bonds directly to fabric with an iron or heat press, skipping stitching for a clean, low-profile finish.
Certified visibility performance: The tape meets EN471 Class II and ANSI/ISEA 107-2010 Class II requirements, giving buyers a documented safety standard to cite.
Stable twill backing: A firm woven twill ground keeps the reflective face flat and wrinkle-free through the heat-pressing process.
Multi-color availability: Grey, silver, yellow and orange are stocked, with custom color matching offered for brand-specific programs.
Reflective tape from a variety of different brightness heat reflective film with a variety of sizes, colors, ribbon heating a paste made of reflective, high strength, use a very square pan, easy to use, fast, mainly suitable for sports gloves, bags, protective clothing (reflective vests), hats, pet clothes and so on.
Reflective Tape Technical Index
Parameter | Description | Typical Value/Standard |
Retroreflectivity (RA, cd/lx/m²) | Measures brightness at night—higher values indicate stronger reflection. | - Standard: ≥50 (EN ISO 20471) |
Observation Angle | Reflectivity decreases as the light source angle increases (e.g., 30° or 45°). | Tested at 0° (direct), 30°, and 45° angles. |
Color & Colorfastness | Reflective colors (silver, fluorescent yellow/orange/red) and fade resistance. | AATCC or ISO 105-B02 colorfastness tests. |
Wash Resistance | Retroreflectivity retention after washing. | ≥70% after 50 washes (EN ISO 6330). |
Abrasion Resistance | Wear resistance (e.g., Martindale test). | ≥10,000 cycles (ASTM D4966). |
Temperature Range | Operational limits. | -30°C to 70°C (no cracking or delamination). |
UV Resistance | Performance retention under sunlight. | ≤10% reflectivity loss after 500h QUV. |
Reflective Tape Performance & Care Specifications
Retroreflective coefficient | 20-450cd/lux.m2 |
Care guide | Home washing 25times at 60℃; Dry-washing 5 times |
Certificate | EN471 CLASS Ⅱ; ANSI/ISEA 107-2010 CLASS Ⅱ; OEKO-TEX 100 |
Feature | Abrasion resistance; Washing resistance; Soft and lightweight |
Customization Services
Retroreflectivity Customization
The reflectivity of reflective tape refers to its ability to reflect light, offers a reflectivity range of 30 to 500 CPL, higher values mean brighter nighttime visibility for enhanced safety across applications from workwear to traffic signs.
CPL≤30
100≤CPL≤150
260≤CPL≤330
400≤CPL≤500
Type Customization
Reflective tapes come in various types, including polyester, fabric, tc, oxford, flame retardant, and heat transfer, each offering different levels of reflectivity and durability for specific applications.
Polyester Reflective Tape
T/C Reflective Tape
Fabric Reflective Tape
Flame Retardant Reflective Tape
Woven Reflective Caution Tape
Reflective Stitching Caution Tape
Oxford Caution Tape
Flame Retardant Reflective Caution Tape
Reflective Grid Tape
Reflective Grid Tape
Heat Transfer Reflective Film
Reflective Woven Film
Usage
Reflective tape is used to improve visibility and safety in various applications, including traffic signs, vehicles, workwear, and outdoor gear, especially in low-light conditions.
