50mm Sew-On Reflective Tape for High-Visibility Workwear
Sew-On High-Visibility Retro-Reflective Safety Tape
| Backing Fabric Material: | 100% polyester, T/C |
| Width: | 5.0cm |
| CPL: | CPL>400 |
| Type: | Fabric Reflective Tape |
| Color: | Silver, yellow (custom ones available) |
| Packaging: | 50-200m/roll |
| MOQ: |
|
◆ Lead Time: 25-35 days
◆ Shipping: Sea freight, Railway freight
◆ Payment: T/T, L/C ...
Product Details
MH sew-on high-visibility retro-reflective tape is a fabric-backed reflective trim built for stitching onto safety vests, workwear, and outdoor apparel.
The tape's retro-reflective surface bounces vehicle headlights and other light sources back toward the source, improving wearer visibility in low-light and night-time conditions. Its soft, flexible construction sews cleanly into medium to heavy-weight fabrics without stiffening the seam, and it is recommended for garments such as safety vests, jackets, reflective vests, tents, backpacks, and cycling apparel.
Sew on or iron on reflective tape, high visibility
Recommended for medium to heavy weight fabrics, such as high-quality safety vests or jackets.
Sew on for safety clothing, reflective vest, tent, backpack, car clothing, cycling jeans, pet clothes, etc.
Reflective Tape Technical Index
| Parameter | Description | Typical Value/Standard |
| Retroreflectivity (RA, cd/lx/m²) | Measures brightness at night—higher values indicate stronger reflection. | - Standard: ≥50 (EN ISO 20471) - High-Intensity: ≥300 (ANSI 107) |
| Observation Angle | Reflectivity decreases as the light source angle increases (e.g., 30° or 45°). | Tested at 0° (direct), 30°, and 45° angles. |
| Color & Colorfastness | Reflective colors (silver, fluorescent yellow/orange/red) and fade resistance. | AATCC or ISO 105-B02 colorfastness tests. |
| Wash Resistance | Retroreflectivity retention after washing. | ≥70% after 50 washes (EN ISO 6330). |
| Abrasion Resistance | Wear resistance (e.g., Martindale test). | ≥10,000 cycles (ASTM D4966). |
| Temperature Range | Operational limits. | -30°C to 70°C (no cracking or delamination). |
| UV Resistance | Performance retention under sunlight. | ≤10% reflectivity loss after 500h QUV. |
Reflective Tape Performance & Care Specifications
| Retroreflective coefficient | 20-450cd/lux.m2 |
| Care guide | Home washing 25times at 60℃; Dry-washing 5 times |
| Certificate | EN471 CLASS Ⅱ; ANSI/ISEA 107-2010 CLASS Ⅱ; OEKO-TEX 100 |
| Feature | Abrasion resistance; Washing resistance; Soft and lightweight |
Retroreflectivity Customization
Type Customization
Usage
Reflective tape is used to improve visibility and safety in various applications, including traffic signs, vehicles, workwear, and outdoor gear, especially in low-light conditions.
