Thermal Bonded Double Dot Nonwoven Interlining Fabric

1 / 4

Double-Dot Thermal Bonded Nonwoven Interlining with Secure Two-Layer Fusing

Thermal Calendaring Nonwoven Interlining

Thermal Bonded Double Dot Nonwoven Interlining Fabric

Material:	100% Polyester
Width:	90-150cm
Weight:	23-80g/m²
Color:	Black, white, grey
Glue Powder:	PA, PES, PA+PES
Packaging:	50m/roll, 10roll/sack
MOQ:	MOQ: 5000m/color MOA: 3000 dollars (no restriction on the types of products) Note for High Market Share Regions: West African: 5000 dollars
Certification:	OEKO-TEX® CERTIFIED Download PDF $oeko tex woven interlining qr code$

Lead Time: 25-35 days
Shipping: Sea freight, Railway freight
Payment: T/T, L/C ...

WhatsApp Contact Us

MH Non-woven Interlining Factory

$14 million
Production Capacity
200+
Workers

View More About MH Industrial

About Ningbo MH

MH specializes in garment accessories and fabrics, offering high-quality solutions for the textile and home décor industries. With advanced automated warehousing, MH ensures efficient supply chain management and provides comprehensive after-sales support, exclusively serving businesses, not individuals.

View More About MH Company

1999
Since
$871Million
Annual Sales (2025)
40+
Branch Offices
600+
Office Staffs

Product Details

Weight: 23-80g/m²

Width: 90-150CM

Material: polyester, polyester+nylon

Model: 8018, 8025, 8030, 8040, 8050 etc

Glue Powder: PA, PES, PA+PES

MOQ: 5000m/color.

Color: Black, white, grey

Packaging: 50m/roll, 100m/roll, according to customer's need.

MH thermal bonded double-dot nonwoven interlining is a calendar-bonded fusible interlining coated with a two-layer PA or PES adhesive dot for hot-fusing to garment panels.

The web is offered from 23 to 80 gsm and 90 to 150 cm wide, with PA, PES or PA+PES glue to match different fusing presses and fabrics.

MH produces this double-dot interlining in white, black and grey or a custom shade. It fuses cleanly onto collars, cuffs, front plackets and other structured areas of shirts, suits, jackets and workwear.

Key Selling Points

Secure two-layer dot bond: MH thermal bonded double-dot nonwoven interlining uses a two-layer adhesive dot that grips both the interlining and the face fabric, giving a strong, durable fused bond.
Resists strike-through: The double-dot structure helps keep adhesive from bleeding to the outer cloth during pressing, so fused garments stay clean-faced through washing and dry cleaning.
Choice of glue chemistry: MH offers PA, PES or PA+PES glue on this double-dot interlining, letting garment makers match the fusing temperature and wash resistance their fabric needs.
Stable calendared hand: Thermal calendaring gives this nonwoven interlining an even, stable hand that supports collars, cuffs and plackets without over-stiffening the garment.
Custom weight and width: MH runs this double-dot interlining across a range of weights and widths, so tailors and factories can specify the right body for each garment area.
OEKO-TEX certified production: MH produces this nonwoven interlining under OEKO-TEX Standard 100 where applicable, supporting apparel brands with export compliance needs.

Application: Used for collar, cuff or front placket of shirt, jacket, or suits.

Fusing Conditions

Type	Machine Temperature	Actual Temperature	Pressure	Time
Continuous Press	130~150℃	127~143 ℃	1.5~2.5kg/cm²	12~15S
Flat Bed Press	130~150℃	127~143℃	0.8~1.5kg/cm²	12~15S

PS: To achieve the best adhesive effect, it is recommended to conduct an adhesion test before production.

MH Thermal Calendaring Nonwoven Interlining Feature

Softness and Flexibility
The nonwoven fabric maintains a soft and flexible texture, making it comfortable for use in garments and other applications where tactile properties are important.
Good Air Permeability
The double dot bonding pattern allows for excellent air permeability, ensuring breathability, which is essential for comfort in apparel and hygiene products.
OEKO-TEX Certification
The nonwoven interlining has passed the OEKO-TEX standard, ensuring that it is free from harmful substances and safe for human use.
Wide range of applications
This nonwoven fabric is ideal for apparel linings, medical & hygiene industry and automotive components.
